VCXO
Select any parameter below to start.
Datasheet Part Number Frequency Range Supply Voltage
Output Logic
Dimensions L * W / type
Height (mm)
Operating Temperature (°C)
G8
1.25 ~ 50MHz 3.3 CMOS 12.8x 12.8 / DIP 4 PIN 5.5 -40 to +85
G8
1.25 ~ 50MHz 5.0 CMOS 12.8x 12.8 / DIP 4 PIN 5.5 -40 to +85
G14
16 ~ 50MHz 1.8 CMOS 20.2x 12.8 / DIP 4 PIN 6.0 -40 to +85
G14
1.25 ~ 50MHz 2.5 CMOS 20.2x 12.8 / DIP 4 PIN 6.0 -40 to +85
G14
1.25 ~ 50MHz 3.3 CMOS 20.2x 12.8 / DIP 4 PIN 6.0 -40 to +85
G14
1.25 ~ 50MHz 5.0 CMOS 20.2x 12.8 / DIP 4 PIN 6.0 -40 to +85
GTQF326
10 ~ 250MHz 2.5 CMOS 3.2 x 2.5 / SMD 6 PAD 1.0 -40 to +85
GTQF326
10 ~ 250MHz 3.3 CMOS 3.2 x 2.5 / SMD 6 PAD 1.0 -40 to +85
GPQF326
10 ~ 1500MHz 2.5 LVPECL 3.2 x 2.5 / SMD 6 PAD 1.0 -40 to +85
GPQF326
10 ~ 1500MHz 3.3 LVPECL 3.2 x 2.5 / SMD 6 PAD 1.0 -40 to +85
GDQF326
10 ~ 1500MHz 2.5 LVDS 3.2 x 2.5 / SMD 6 PAD 1.0 -40 to +85
GDQF326
10 ~ 1500MHz 3.3 LVDS 3.2 x 2.5 / SMD 6 PAD 1.0 -40 to +85
GTQN326
10 ~ 250MHz 2.5 CMOS 3.2 x 2.5 / SMD 6 PAD 1.0 -40 to +85
GTQN326
10 ~ 250MHz 3.3 CMOS 3.2 x 2.5 / SMD 6 PAD 1.0 -40 to +85
GPQN326
10 ~ 1500MHz 2.5 LVPECL 3.2 x 2.5 / SMD 6 PAD 1.0 -40 to +85
Total: 120 entries
