VCXO
Select any parameter below to start.
Datasheet Part Number Frequency Range Supply Voltage
Output Logic
Dimensions L * W / type
Height (mm)
Operating Temperature (°C)
GTQN536
10 ~ 250MHz 2.5 CMOS 5.0 x 3.2 / SMD 6 PAD 1.2 -40 to +85
GTQN536
10 ~ 250MHz 3.3 CMOS 5.0 x 3.2 / SMD 6 PAD 1.2 -40 to +85
GPQN536
10 ~ 1500MHz 2.5 LVPECL 5.0 x 3.2 / SMD 6 PAD 1.2 -40 to +85
GPQN536
10 ~ 1500MHz 3.3 LVPECL 5.0 x 3.2 / SMD 6 PAD 1.2 -40 to +85
GDQN536
10 ~ 1500MHz 2.5 LVDS 5.0 x 3.2 / SMD 6 PAD 1.2 -40 to +85
GDQN536
10 ~ 1500MHz 3.3 LVDS 5.0 x 3.2 / SMD 6 PAD 1.2 -40 to +85
GCTQF536
10 ~ 250MHz 2.5 CMOS 5.0 x 3.2 / SMD 6 PAD 1.2 -40 to +85
GCTQF536
10 ~ 250MHz 3.3 CMOS 5.0 x 3.2 / SMD 6 PAD 1.2 -40 to +85
GCPQF536
10 ~ 1500MHz 2.5 LVPECL 5.0 x 3.2 / SMD 6 PAD 1.2 -40 to +85
GCPQF536
10 ~ 1500MHz 3.3 LVPECL 5.0 x 3.2 / SMD 6 PAD 1.2 -40 to +85
GCDQF536
10 ~ 1500MHz 2.5 LVDS 5.0 x 3.2 / SMD 6 PAD 1.2 -40 to +85
GCDQF536
10 ~ 1500MHz 3.3 LVDS 5.0 x 3.2 / SMD 6 PAD 1.2 -40 to +85
GTJF538
15 ~ 250MHz 1.8 CMOS 5.0 x 3.2 / SMD 8 PAD 1.4 -40 to +85
GTJF538
15 ~ 250MHz 2.5 CMOS 5.0 x 3.2 / SMD 8 PAD 1.4 -40 to +85
GTJF538
15 ~ 250MHz 3.3 CMOS 5.0 x 3.2 / SMD 8 PAD 1.4 -40 to +85
Total: 120 entries
