TCXO / VCTCXO
Select any parameter below to start.
Datasheet Part Number Frequency Range Supply Voltage ( V )
Output Logic
Dimensions L * W / type
Height ( mm )
Temp. Stabilit
M15S
6.4 ~ 52MHz 5.0 Clipped Sine Wave 20.2 x 12.8 / DIP 4 PIN 7.0 ± 1ppm / -40 to +85℃
M39S
6.4 ~ 52MHz 1.8 Clipped Sine Wave 18.4 x 11.7 / DIP 4 PIN 4.7 ± 1ppm / -40 to +85℃
M39S
6.4 ~ 52MHz 2.5 Clipped Sine Wave 18.4 x 11.7 / DIP 4 PIN 4.7 ± 1ppm / -40 to +85℃
M39S
6.4 ~ 52MHz 3.0 Clipped Sine Wave 18.4 x 11.7 / DIP 4 PIN 4.7 ± 1ppm / -40 to +85℃
M39S
6.4 ~ 52MHz 3.3 Clipped Sine Wave 18.4 x 11.7 / DIP 4 PIN 4.7 ± 1ppm / -40 to +85℃
M39S
6.4 ~ 52MHz 5.0 Clipped Sine Wave 18.4 x 11.7 / DIP 4 PIN 4.7 ± 1ppm / -40 to +85℃
M572T
32.768kHz 2.5 CMOS 7.0 x 5.0 / SMD 4 PAD 2.5 ± 1ppm / -40 to +85℃
M572T
32.768kHz 3.0 CMOS 7.0 x 5.0 / SMD 4 PAD 2.5 ± 1ppm / -40 to +85℃
M572T
32.768kHz 3.3 CMOS 7.0 x 5.0 / SMD 4 PAD 2.5 ± 1ppm / -40 to +85℃
M572T
6.4 ~ 52MHz 1.8 CMOS 7.0 x 5.0 / SMD 4 PAD 2.3 ± 1ppm / -40 to +85℃
M572T
1.25 ~ 52MHz 2.5 CMOS 7.0 x 5.0 / SMD 4 PAD 2.3 ± 1ppm / -40 to +85℃
M572T
1.25 ~ 52MHz 3.0 CMOS 7.0 x 5.0 / SMD 4 PAD 2.3 ± 1ppm / -40 to +85℃
M572T
1.25 ~ 52MHz 3.3 CMOS 7.0 x 5.0 / SMD 4 PAD 2.3 ± 1ppm / -40 to +85℃
M572T
1.25 ~ 52MHz 5.0 CMOS 7.0 x 5.0 / SMD 4 PAD 2.3 ± 1ppm / -40 to +85℃
M8T
32.768kHz 1.8 CMOS 12.8 x 12.8 / DIP 4 PIN 5.5 ± 1ppm / -40 to +85℃
Total: 206 entries
